Replacement Parts for the VIPER Hydraulic kit

A. Air Tank Shutoff (975-00180)
B. Air Tank 91 Cu. In. 4500 PSI with Regulator (975-00179)
D. Complete Rebuilding Kit for Hydraulic Device (010-4022)
E. Arborjet Hydraulic Dosesizer Assembly (951-11005)
F. Tree Pressure Gauge Assembly (010-4031)
G. Air Hydraulic Regulator Assembly (010-2007)
H. Low Pressure Gauge Assembly (010-2006)
I. High Pressure Gauge Assembly (975-0166)
J. Spray Shield Device (010-2010)
K. Medicament Shut Off Switch (975-00016)
L. Medicament Bottle Adaptor with Washer (010-2050)
M. Medicament Bottle Washer 10 pk (070-0524)
N. Low Pressure 25lb Medicament Quick Disconnect- Female (975-00099)
O. Low Pressure 25lb Medicament Quick Disconnect- Male (975-00100)
P. Barb 10-32/170 (975-00019)
Q. Medicament Bottle HP – 1000 ml (010-9022)
R. Arborjet Hydraulic Device 5 ml Viper with Dosesizer (010-0003)

VIPER Hydraulic parts diagrams
